Product Description
Why Choose a 16+2 Web Managed PoE Switch?
When your network grows beyond 8 PoE devices, an unmanaged switch quickly becomes a bottleneck. This 16-port Gigabit PoE Web Managed Switch combines high port density, 200W PoE budget, and full Web management to support medium-to-large deployments.
Powered by an MTK chipset, it delivers a 102Gbps switching capacity and 75.888Mpps forwarding rate, ensuring smooth data transmission even under heavy load. The 200W PoE budget can power multiple PTZ cameras, high-power wireless APs, and VoIP phones simultaneously. With Web-based management, you can configure VLANs, QoS, port mirroring, and security policies directly from a browser — no CLI required.
Key Design Highlights
-
16× Gigabit PoE Ports + 2× Gigabit Uplink Ports
High-density connectivity for access and aggregation layers. -
200W PoE Power Budget
Supports multiple high-power PoE devices, including PTZ cameras and 802.11ax APs. -
MTK Chipset with Web Management
Stable switching performance with browser-based configuration. -
Advanced VLAN Support
MTU VLAN, Port VLAN, 802.1Q VLAN, Voice VLAN, and Surveillance VLAN. -
Comprehensive QoS & Security
QoS basic/advanced configuration, MAC management, storm suppression, traffic monitoring, cable detection, and DHCP Snooping. -
Reliable Network Protocols
IGMP Snooping, link aggregation, loop protection, port mirroring, port rate limiting, jumbo frame, EEE, SNMP, and RSTP/STP. -
IP30 Metal Housing
High-quality metal case with excellent heat dissipation for stable operation. -
Easy Web Access
Default IP: 192.168.2.254; default username/password: admin. -
Compact & Lightweight
Dimensions: 300×175×46mm (excluding protrusions); weight: 2.1kg.
Applications
-
Medium-to-large IP surveillance networks
-
Dense wireless AP coverage
-
VoIP telephony
-
Enterprise access/aggregation layers
-
Smart building and industrial automation
Specification
| Parameter | Technical Specification |
|---|---|
| Product Type | Managed Full Gigabit PoE Ethernet Switch |
| Model | ZSTX-IND9216Wp-DF-1 |
| Ports | 16× PoE 10/100/1000M RJ45 + 2× 10/100/1000M RJ45 Uplink |
| PoE Budget | 200W |
| Power Consumption | < 200W (full load) |
| Input Voltage | AC 176V–264V |
| Power Supply | Built-in DC 52V 4.5A |
| Switching Capacity | 102Gbps |
| Forwarding Rate | 75.888Mpps |
| MAC Address Table | 8K |
| Network Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3x |
| Network Topology | Ring, star, bus, tree |
| VLAN | MTU VLAN, Port VLAN, 802.1Q VLAN, Voice VLAN, Surveillance VLAN |
| QoS | Basic & advanced QoS configuration |
| Management | Web management, SNMP, IGMP Snooping, RSTP/STP, link aggregation, port mirroring, port rate limiting, jumbo frame, EEE |
| Security | MAC management, storm suppression, traffic monitoring, cable detection, DHCP Snooping |
| Tools | System upgrade, Ping, backup/restore, system recovery, configuration save, system reboot |
| Reset | Long press 7s to restore factory settings |
| LED Indicators | PWR, POE (red), Link/Act (blue), SYS |
| Protection Rating | IP30 |
| Housing | High-quality metal |
| MTBF | 100,000 hours |
| Operating / Storage Temp. | -10℃ ~ +70℃ |
| Relative Humidity | 5% ~ 95% (non-condensing) |
| Dimensions (W×D×H) | 300 × 175 × 46 mm (excluding protrusions) |
| Weight | 2.1 kg/unit |
| Package | 12 units/carton |
| Package Contents | Switch ×1, Power Cord ×1, User Manual ×1, Certificate ×1, Warranty Card ×1 |
| Default IP | 192.168.2.254 |
| Default Login | admin / admin |
Faq
Q1: What is a 16+2 Web Managed PoE switch?
A: It is a Gigabit PoE switch with 16 PoE ports and 2 uplink ports, featuring Web-based management for VLAN, QoS, security, and network monitoring.
Q2: How many PoE ports does this switch have?
A: 16× Gigabit PoE ports and 2× Gigabit uplink ports.
Q3: What is the PoE budget?
A: 200W total PoE budget.
Q4: What chipset does it use?
A: MTK chipset for reliable switching performance.
Q5: Is it Web managed?
A: Yes. You can access the Web interface via default IP 192.168.2.254 with username/password admin.
Q6: What VLAN features are supported?
A: MTU VLAN, Port VLAN, 802.1Q VLAN, Voice VLAN, and Surveillance VLAN.
Q7: What management protocols are supported?
A: SNMP, IGMP Snooping, RSTP/STP, link aggregation, port mirroring, port rate limiting, jumbo frame, and EEE.
Q8: What security features are included?
A: MAC management, storm suppression, traffic monitoring, cable detection, and DHCP Snooping.
Q9: What is the switching capacity and forwarding rate?
A: 102Gbps switching capacity and 75.888Mpps forwarding rate.
Q10: What is the MAC address table size?
A: 8K MAC addresses.
Q11: What is the operating temperature range?
A: -10℃ to +70℃.
Q12: What is the protection rating and housing material?
A: IP30 protection rating with a high-quality metal housing.
Q13: What is the MTBF?
A: 100,000 hours.
Q14: What is included in the package?
A: Switch ×1, Power Cord ×1, User Manual ×1, Certificate ×1, Warranty Card ×1.
Q15: What is the default IP and login?
A: Default IP: 192.168.2.254; default username/password: admin/admin.
Q16: Does it support high-power PoE devices?
A: Yes. With a 200W PoE budget, it can power PTZ cameras, high-power wireless APs, and VoIP phones.
Q17: What is the switching mode?
A: Store-and-forward.
